Battery Cell Test Bench
FKFS has a modern battery cell test bench for analyzing battery cells for electrified powertrains under defined thermal boundary conditions. This enables us to investigate a whole range of topics: from determining the capacity of single cells, running test cycles to provide detailed characterization of the electric cell properties and the resulting heat flows, right up to battery aging studies.
Contact
Dr.-Ing. Timo Kuthada
Ph.: +49 711 685-67615
Technical Data
Voltage range | 0 - 6 V |
Current range | ± 240 A |
Temperature range | - 40 – + 180°C |
Max. temperature gradient | 5 K/min |
Volume of test chamber | 115 l |
Accuracy of voltage measurement | 0,05% full scale value |
Accuracy of current measurement | 0,05% full scale value |
